LTL-6210MM User Manual

LTL-6210MM 1080P H.264 MMS Hunting Camera

12MP 1080P HD video MMS scouting trail camera

HD Video decoding H.264 1080p

Digital Trail Cameras, Ltl Acorn, 6210MM, Scouting Camera, Game Cameras, Ltl acorn 6210MM 12MP 1080P HD video MMS scouting trail camera hunting camera ltl-6210MC Ltl-6210MM MMS camera, and Scouting Cameras Motion Activated Wildlife Cameras | Ltl 6210MM Ltl 6210MC 12MP Hunting camera,trigger time 1.2S,2.0 inch LCD ... LTL Acorn HD 1080P 12MP Trail Camera 940NM (No Glow IR) - LTL-6210M, 12MP Hunting/ Scouting Camera and China Game Camera,Trail Camera | Chinese trail camera manufacturer,hunting camera supplier | Videsur is a professional hunting camera manufacturer & trail camera supplier which manufacturing the best trail cameras -Ltl Acorn | wildlife camera, trail camera,deer camera, MMS hunting camera,GSM hunting camera and camera trail | digital hunting camera | Digital Trail Cameras | Stealth Cam Digital Scouting Cameras | Wildview Digital Scouting Cameras | Infrared Digital Scouting Camera | Wholesale - 5MP/12MP Digital Hunting Camera/Game Scouting Camera/Hunting Trail Cameras/Game Camera/Deer Trail Camera wholesale in china | 12mp digital scouting camera | Complete Wildlife Camera Range | Scouting & Trail Cameras | 940nm Trail Camera Manufacturers & 940nm Trail Camera Supplier | invisible 940nm light 12mp digital trail Camera invisiable 940NM LED hunting camera | NEW Little Acorn 12MP Trail Camera LTL-5210A 940NM LED | Invisible 940nm Light 12mp Digital Trail Camera,Hunting Video Camera | Scouting Camera, Garden camera |

--------------------------------------------------------------------

 Description:

Ltl acorn ltl-6210MC Ltl-6210MM MMS camera 12MP HD video MMS hunting camera scouting trail camera

Ltl Acorn Model Ltl-6210M The Ltl Acorn Ltl-6210M is a step-up to Ltl-5210M. It provides enhanced features and better performances. Bundled with the MMS-module (Multimedia Messaging Service) (Part # LTL-MM2), the standard scouting camera (Part # Ltl-6210MC be upgraded to work as a remote cellular camera. With its highly sensitive Passive Infra-Red (PIR) sensor, the camera detects the sudden change of ambient temperature caused by moving game in a region of interest (ROI), triggers to take pictures/videos, and sends the images via GSM network to the user¡¯s cell phone or email account.

There are two selects of IR LED on the Ltl-6210M series camera, 850nm and 940nm. The former provides up to 82-foot flash range whereas the latter up to 42-foot flash range. The of 940nm IR LED, however, is it emits no-glow flash that is invisible in the dark.



* at very close range, 3 feet or less, there is still noticeably a fairly faint glow if you look directly into the LEDs. Both this model and the standard model emit infra red light that is invisible to humans and animals, however in the standard model the small LEDs themselves can be seen to be red when activated.

Model

Parameters

6210MM

Image Sensor

12 Mega Pixels Color CMOS

Yes

Max. Pixel Size

2560x1920

Yes

Lens

F=3.1; FOV=52¡ã; Auto IR-Cut

Yes

IR Flash

850nM:82 Feet/25 Meters

940nM:42 Feet/13 Meters

Yes

LCD Screen

40.8x30.6mm(2.0"); 960(RGB)*240DOT;16.7M Color

Yes

Operation Keypad

6 Keys

Yes

Memory

SD Card (8MB ~32GB)

Yes

Picture Size

5MP/12MP/2MP = 2560X1920/4000X3000/1600X1200;

Yes

Video Size

1440x1080: 15 fps; 1280x720: 30fps; 640x480: 30fps;

Yes

PIR Sensitivity

High/Normal/Low

Yes

PIR Sensing Distance

82ft/25m(Below 77¡ãF/25¡ãC at the Normal Level)

Yes

Prep PIR  Sensing Angle

Left and right light beams form an angle of 100¡ã; Each lens covers 10¡ã

Yes

Main PIR Sensing Angle

35¡ã

Yes

Operation Mode

Day/Night

Yes

Trigger Time

1.2Second (When using the 2G SD card)

Yes

Trigger Interval

0sec. - 60min; Programmable

Yes

Shooting Numbers

1~3

Yes

Video Length

1-60sec ; Programmable

Yes

Camera + Video

First take Picture then Video

Yes

Playback Zoom In

1~16 Times

Yes

Time Stamp

On/Off; Include serial No., temperature and moon phase

Yes

Timer

On/Off; Programmable

Yes

Password

4-Digit Numbers

Yes

Device Serial No.

4 digits and 26 alphabets set by yourself

Yes

Time Lapse

On/Off; 1 Second ~ 24 Hours Programmable

Yes

SD Card cycle

Save

On/Off;

Yes

MMS Options

VGA=640x480;SMS;OFF

Programmable

Yes

MMS Numbers

¡°0¡± = Unlimited; 0 ~ 99/Day

Yes

MMS Phone No.

1~3 Phone Numbers

Yes

MMS E-mail

0~3 E-mail address

Yes

SMS

1-3

Yes

Low-Battery SMS Alert

"Battery Low¡± text alert sent

Yes

language setting

Change Country Can Setting

Language

Yes

Power Supply

12xAA;

Yes

External DC Power Supply

Plug Size: 4.0x1.7

6-12V (1 ~ 2A)

Yes

Stand-by Current

0.4mA

Yes

Stand-by Time

4-6 Months(12xAA)

Yes

Auto Power Off

Auto power off in 2 minutes if no keypad input

Yes

Power Consumption

150mA (+350mA when IR LED lights up)

Yes

Low Battery Alert

4.2~4.3V

Yes

Interface

TV out; USB; SD Card and SIM Slot ,6V DC External

Yes

Mounting

Strap; Tripod

Yes

Waterproof

IP54

Yes

Operation Temperature

-22~+158¡ãF/-30 ~+70¡ãC

Yes

Operation Humidity

5% ~ 95%

Yes

Certificate

FCC & CE & ROHS

Yes



Each photo can optionally be stamped with the date, time, temperature, moon status.

Day photo: example 1; example 2



Night photo: example 1

Large TFT-LCD screen for playback of photos & Video. Cameras can take photos and video day and night, and also has unique time-lapse setting option which is not found on other trail cameras - see the wood or field throughout the day, watch how animals move and plants grow.

`````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````````

 Features:

¡¤ 5M/12M/2M pixel high-quality resolution.

¡¤ 1440 x 1080 / 1280 x 720 / 640x480 H.264/AVC format HD video with audio Infrared night vision LEDs 850nm for flash range as far as 75 feet (25m) (No-glow model 940nm has 39 feet (13m) flash range)

¡¤ ¡°Cam + Video¡± mode enables camera to take both picture and video at every trigger event Continuous shooting interval time about 0.5 or 1.0 seconds (stamp off or On)

¡¤ Extremely long in-field life (in standby mode, up to 6 months with 12 x AA batteries)

¡¤ Unique side Prep Sensor design provides wider sensing angle and enhances camera¡¯s response speed

¡¤ Perform in the most extreme temperatures from -22¡ãF (-30¡ãC) to 158¡ãF (70¡ãC)

¡¤ Compact size (5.5 x 3.5 x 3 inches). Well designed to deploy covertly Impressively quick trigger time (1.2 second)

¡¤ Programmable to work as Time-Lapse camera taking pictures/videos in long range day and night

¡¤ When Timer setting on, programmable to only work in specified period every day. This feature can be used together with Time Lapse feature to meet your timetable

¡¤ In camera¡¯s bottom cover built-in 2.0¡± TFT color display to review images and videos.

¡¤ Date, time, temperature, moon phase and battery level can be stamped on picture

¡¤ Lockable and password protected

¡¤ Send 640 x 480 resolution MMS image

¡¤ Setup is a snap by running the user-friendly software on the enclosed CD on the computer, or directly on the built-in TFT display.

¡¤ Can change several language of the menu through setting country in MMS menu or in PC Setup

¡¤ Separation of the Camera and the MMS module provides users flexibility: starting with the value models a standard scouting camera, and upgrading to the premium model with MMS function.

¡¤ SD card can be set in ¡°Cycling Save¡± mode, which automatically deletes the earliest photos or videos and makes room for new ones.

¡¤ Advanced Remote Cellular Technology transmits images to your cell phone and/or email account constantly at lower battery consumption and shorter transmission time, compared to products of its kind on the market.

¡¤ Text alert when battery power level goes low

¡¤ Check cellular signal reception on the built-in TFT display on the field

¡¤ Internal antenna design. External antenna is available when using security box.

¡¤ Operates globally via GSM/GPRS network. Supports four bands: 850 / 900 / 1800 /1900MHz.





Accessories:
Kit includes: LTL-6210MM Camera in camouflage /Addition battery box /TV AV IN cable/USB cable/Belt/Manual/Guarantee card/LCD protector

Package:

Digital Camera 1
MM2 MMS Mode 1
TV AV IN Cable 1
USB Cable 1
Strap 1
External DC Cable (optional)
Installation CD 1
Warranty Card 1



¡¡
